Description
Series | 10 Series |
Material | Stainless-Steel |
Grade | 304 Stainless |
Finish | Stainless |
Color | N/A |
A | .630″ |
B | .213″ |
C | .386″ |
D (Thread) | M6 X 1.0 |
E | .253″ |
F | .203″ |
Weight | 0.009000 |

The roll-in T-nut with ball spring is a fastening option that loads from the profile ends or side, which is helpful for applications where the ends are inaccessible. The ball spring holds the T-nut in the T-slot, even when the profile is in a vertical position, simplifying the assembly process. It is available with options in size, material, thread, and finish.
Part No: 3668
$7.41
Series | 10 Series |
Material | Stainless-Steel |
Grade | 304 Stainless |
Finish | Stainless |
Color | N/A |
A | .630″ |
B | .213″ |
C | .386″ |
D (Thread) | M6 X 1.0 |
E | .253″ |
F | .203″ |
Weight | 0.009000 |
Brand |
---|
No CAD files available for this product.
